| GPU | 512-Core Volta GPU with Tensor Cores |
| CPU | 8-Core ARM v8.2 64-Bit CPU, 8 MB L2 + 4 MB L3 |
| Memory | 16 GB 256-Bit LPDDR4x | 137 GB/s |
| Storage | 32 GB eMMC 5.1 |
| DL Accelerator | (2x) NVDLA Engines* |
| Vision Accelerator | 7-Way VLIW Vision Processor* |
| Encoder/Decoder | (2x) 4Kp60 | HEVC/(2x) 4Kp60 | 12-Bit Support |
| Size | 105mm x 105mm |
| Deployment | Module (Jetson Xavier) |
| Product Weight w/ Packaging | 1548g |
| Package Dimension | 223(L) x 209(W) x 134(H)mm |
| DEVELOPER KIT I/Os | JETSON XAVIER MODULE INTERFACE |
| PCIe x16 | x8 PCIe Gen4/x8 SLVS-EC |
| RJ45 | Gigabit Ethernet |
| USB-C | 2x USB 3.1, DP (Optional), PD (Optional) |
| USB-C | Close-System Debug and Flashing Support on 1 Port |
| Camera Connector | (16x) CSI-2 Lanes |
| M.2 Key M | NVMe |
| M.2 Key E | PCIe x1 + USB 2.0 + UART (for WiFi/LTE)/I2S/PCM |
| 40-Pin Header | UART + SPI + CAN + I2C + I2S + DMIC + GPIOs |
| HD Audio Header | High-Definition Audio |
| eSATAp + USB3.0 Type A | SATA Through PCIe x1 Bridge (PD + Data for 2.5 inch SATA) + USB 3.0 |
| HDMI Type A/eDP/DP | HDMI 2.0, eDP 1.2a, DP 1.4 |
| uSD/UFS Card Socket | SD/UFS |
*Please refer to NVIDIA documentation for what is currently supported.
