* 算力: 可提供高達 40 TOPS 的 AI 性能
* Other I/O
> 2x MIPI CSI-2 22-pin camera connectors
> 2x M.2 Key M, M.2 Key E
> 4x USB 3.2 Gen2 Type-A
> USB Type-C for UFP
> Gigabit Ethernet
> DisplayPort
> microSD slot
> 40-pin expansion header
> DC power jack
|
AI Performance
|
40 TOPS
|
|
GPU
|
1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores
|
|
CPU
|
6-core Arm® Cortex®-A78AE v8.2 64-bit CPU
1.5MB L2 + 4MB L3 |
|
Memory
|
8GB 128-bit LPDDR5
68 GB/s |
|
Storage
|
-
(SD Card Slot & external NVMe via M.2 Key M) |
|
Video Encode
|
1080p30 supported by 1-2 CPU cores
|
|
Video Decode
|
1x 4K60 (H.265)
2x 4K30 (H.265) 5x 1080p60 (H.265) 11x 1080p30 (H.265) |
|
Networking
|
1xGbE Connector
|
|
CSI Camera
|
2x MIPI CSI-2 22-pin Camera Connectors
|
|
Display
|
1x DisplayPort 1.2 (+MST) connector
|
|
USB
|
USB Type-A Connector: 4x USB 3.2 Gen2
USB Type-C Connector for UFP |
|
Other I/O
|
40-Pin Expansion Header(UART, SPI, I2S, I2C, GPIO)
12-pin button header 4-pin fan header microSD Slot DC power jack |
|
Power
|
7W - 15W
|
|
Mechanical
|
100 mm x 79 mmx 21 mm
(Height includes feet, carrier board, module, and thermal solution) |
